YASKAWA V1000 Series Installation & Start-Up Manual

B.2 Parameter Table
YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07) 341
Parameter List
B
b5-10
PID Output Gain
Setting
Sets the output gain of the PID controller.
0.00 to
25.00
1.00 A A A 1AE —
b5-11
PID Output Reverse
Selection
0: Zero Limit (when PID output goes negative,
the drive stops).
1: Drive reverses when PID turns negative.
Zero Limit is automatic when reverse prohibit
is selected using b1-04.
0,1 0 A A A 1AF —
b5-12
PID Feedback
Reference Missing
Detection Selection
0: Disabled. No detection PID feedback loss.
1: Alarm. Detection PID feedback loss.
Continues operation during detection without
triggering a fault contact.
2: Fault. A fault is output and the drive coasts to
stop.
3: PID Feedback error detection disabled.
Multi-function output only, detected during PID
control cancel input only.
4: PID Feedback error detection enabled. An
alarm is triggered and the drive continues to
run. Detected only when PID control is
canceled.
5: PID Feedback error detection enabled. Fault
is triggered and output is shut off. Detected
only when PID control is canceled.
0 to 5 0 A A A 1B0 —
b5-13
PID Feedback Loss
Detection Level
Sets the PID feedback loss detection level as a
percentage (%) of maximum frequency
(E1-04).
0 to 100 0% A A A 1B1 —
b5-14
PID Feedback Loss
Detection Time
Sets the PID feedback loss detection delay time
in terms of seconds.
0.0 to
25.5
1.0 s A A A 1B2 —
b5-15
PID Sleep Function
Start Level
Sets the sleep function start frequency.
Note: Also enabled when PID control mode is
not selected.
0.0 to
400.0
0.0
Hz
AAA 1B3 —
b5-16 PID Sleep Delay Time
Sets the sleep function delay time in units of 0.1
seconds.
0.0 to
25.5
0.0 s A A A 1B4 —
b5-17 PID Accel/Decel Time
Applies an accel/decel time to the PID setpoint
reference. The drive's standard softstarter (C1-
 and S-curve) also affects the output of the
PID algorithm.
0 to
255
0 s A A A 1B5 —
b5-18 PID Setpoint Selection
Configures parameter b5-19 as the PID target
setpoint value.
0: Disabled
1: Enabled
0,1 0 A A A 1DC —
b5-19 PID Setpoint Value
Sets the PID target value.
Use only when b5-18 = 1
0.00 to
100.00
0.00
%
AAA 1DD —
No. Name Description Range Def.
Control
Mode
Addr.
Hex
Pg.
V/f
O
LV
P
M

YASKAWA V1000 Series Specifications

General

Model	V1000 Series
Series	V1000
Output Frequency	0.1 to 400 Hz
Overload Capacity	150% for 60 seconds
Type	AC Drive
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Output Voltage	0 to Input Voltage
Power Range	0.1 to 18.5 kW
Horsepower	0.2 to 25 HP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Interfaces	Modbus RTU
Enclosure	IP20
Ambient Temperature	-10 to +50°C
Storage Temperature	-20 to +60°C
Humidity	5 to 95% RH (non-condensing)
Cooling Method	Fan Cooled
