YASKAWA V1000 Series

B.2 Parameter Table
362 YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07)
E4-03
Motor 2 Rated
No-Load
Current
Sets the magnetizing current of motor 2 in
percentage of full load current (E4-01). This
value is automatically set during Rotational
Auto-Tuning.
0 to less
than [E4-
01]
<21>
<17> AA − 323 —
E4-04
Motor 2 Motor
Poles
Sets the number of poles of motor 2. This
value is automatically set during
Auto-Tuning.
2 to 48 4 poles A A − 324 —
E4-05
Motor 2
Line-to-Line
Resistance
Sets the phase-to-phase resistance of motor 2
in ohms. This value is automatically during
Auto-Tuning.
0.000 to
65.000
<37>
<12> AA − 325 —
E4-06
Motor 2
Leakage
Inductance
Sets the voltage drop due to motor leakage
inductance as a percentage of rated voltage of
motor 2. This value is automatically set
during Auto-Tuning.
0.0 to
40.0
<12> AA − 326 —
E4-07
Motor 2 Motor
Iron-Core
Saturation
Coefficient 1
Set to the motor iron saturation coefficient at
50% of magnetic flux. This value is
automatically set during Rotational
Auto-Tuning.
0.00 to
0.50
0.50 − A − 343 —
E4-08
Motor 2 Motor
Iron-Core
Saturation
Coefficient 2
Set to the motor iron saturation coefficient at
75% of magnetic flux. This value is
automatically set during Rotational
Auto-Tuning.
Setting
for
E4-07 to
0.75
0.75 − A − 344 —
E4-09
Motor 2
Mechanical
Loss
Sets the motor mechanical loss as a
percentage of motor rated power (kW)
capacity. This parameter does not typically
require adjustment. Adjust in the following
circumstances:
When there is a large amount of torque loss
due to motor bearing friction.
When there is a large amount of torque loss.
0.00 to
10.0
0.0 − A − 33F —
E4-10
Motor 2 Iron
Loss
Sets the motor iron loss in watts.
0 to
65535
<12> − A − 340 —
E4-11
Motor 2 Rated
Capacity
Sets the motor rated capacity in units of 0.01
kW. This value is automatically set during
Auto-Tuning.
0.00 to
650.00
<12> AA − 327 —
E4-12
Motor 2
Iron-Core
Saturation
Coefficient 3
Set to the motor iron saturation coefficient at
130% of magnetic flux. This value is
automatically set during Rotational
Auto-Tuning.
1.30 to
5.00
1.30 − A − 342 —
No. Name Description Range Def.
Control
Mode
Addr.
Hex
Pg.
V/f
O
L
V
P
M
