YASKAWA V1000 Series Installation & Start-Up Manual

B.2 Parameter Table
372 YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07)
42
Run Command (2-wire
sequence 2)
Open: Stop
Closed: Run
Note: Settings 40 and 41 cannot be utilized at the same
time.
OOO—
43
FWD/REV Command (2-wire
sequence 2)
Open: Reverse
Closed: Forward
Note: Settings 40 and 41 cannot be utilized at the same
time.
OOO—
44 Offset Frequency 1 Addition
Closed: Add to the main frequency reference.
This function is used with offset frequency 1 (d7-01)
OOO—
45 Offset Frequency 2 Addition Closed: Add to the main frequency reference. (d7-02) O O O —
46 Offset Frequency 3 Addition Closed: Add to the main frequency reference. (d7-03) O O O —
60
DC Injection Braking
Command
Closed: Triggers DC Injection Braking (b2-02) O O - —
61 External Search Command 1
Closed: Executes Speed Search from the maximum
output frequency (E1-04). Based on the b3-01 (Speed
Search at Start).
OOO—
62 External Search Command 2
Closed: Executes Speed Search from the frequency
reference. Based on the b3-01 (Speed Search at Start).
OOO—
65 KEB Ride-Thru (N.C.)
Open: KEB Ride-Thru enabled.
Closed: Normal operation.
OOO—
66 KEB Ride-Thru (N.O.) Closed: Enables KEB Ride-Thru. O O O —
67 Communications Test Mode
Tests the MEMOBUS/Modbus RS-485/422 interface.
Displays, “Pass” if the communication test is successful.
OOO—
68 High-Slip Braking
Closed: High-Slip braking is executed regardless of the
current command and the drive stops.
O- -—
6A Drive Enable
Open: Drive is disabled. If this contact is opened during
run, then the drive will stop as specified by parameter
b1-03.
Closed: Run command can be entered.
OOO—
75 Up 2 Command Open: Maintains the current frequency reference
Closed: Increases or decreases the frequency reference.
UP 2 and Down 2 commands must be set in combination
with each other. The source of the frequency reference
must also be assigned to the control terminals
(b1-01 = “1”).
OOO—
76 Down 2 Command O O O —
7A KEB Ride-Thru 2 (N.C.)
Open: KEB deceleration at momentary power loss
command 2 (N.C. contact)
OOO—
H1 Multi-Function Digital Input Selections
H1-
Setting
Function Description
Control
Mode
Pg.
V/
f
O
LV
P
M

YASKAWA V1000 Series Specifications

General

Model	V1000 Series
Series	V1000
Output Frequency	0.1 to 400 Hz
Overload Capacity	150% for 60 seconds
Type	AC Drive
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Output Voltage	0 to Input Voltage
Power Range	0.1 to 18.5 kW
Horsepower	0.2 to 25 HP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Interfaces	Modbus RTU
Enclosure	IP20
Ambient Temperature	-10 to +50°C
Storage Temperature	-20 to +60°C
Humidity	5 to 95% RH (non-condensing)
Cooling Method	Fan Cooled
