B.2 Parameter Table
376 YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07)
39
Watt Hour Pulse
Output
Output units are determined by H2-06, outputs 200 ms pulse for
each incremented kWh count.
OOO —
3C Drive Mode
Closed: Local
Open: Remote
(this signal combines setting values 9 and A).
OOO —
3D Speed Search Closed: Speed search is being executed. O O O —
3E PID Feedback Loss
Closed: PID Feedback Loss.
PID feedback value (pulse or analog input) is below the level set to
b5-13 for longer than the time set in b5-14.
OOO —
3F PID Feedback Fault
Closed: PID Feedback Fault.
PID feedback value (pulse or analog input) exceeds the level set to
b5-36 for longer than the time set to b5-37.
OOO —
4A KEB Operation Closed: KEB is being performed. O O O —
4B Short-Circuit Brake Closed: The Short-Circuit Brake is active. −−O—
4C During Fast-stop
Closed: A Fast-stop command is entered from the operator or from
the terminals.
OOO —
4D
OH Pre-alarm Time
Limit
Closed: OH Pre-alarm time limit is passed. O O O —
90 to 92
DriveWorksEZ Digital
Outputs 1 thru 3
–OOO—
100 to
192
H2 Parameter
Functions Reversed
Output Switching of 0
to 92
Reverse the output switching of the multi-function output
functions. Set the last two digits of 1 to reverse the output
signal of that specific function.
Examples:
Setting “108” reverses the output of “During baseblock,” which is
setting value 08.
Setting “14A” reverses the output of “During KEB operation”,
which is setting “4A”.
OOO —
H2 Multi-Function Digital Output Settings
H2-
Setting
Function Description
Control
Mode
Pg.
V/
f
O
L
V
P
M
