YASKAWA V1000 Series Installation & Start-Up Manual

B.2 Parameter Table
YASKAWA TM.V1000.01 V1000 Drive Installation & Start-Up Manual (Preliminary 01-19-07) 377
Parameter List
B
No. Name Description Range Def.
Control
Mode
Addr.
Hex
Pg.
V/
f
O
L
V
P
M
H3: Analog Inputs
Use H3 parameters to set the multi-function analog input terminals.
H3-01
Terminal A1 Signal
Level Selection
Sets the input level for terminal A1.
0: 0 to +10 V (lower limit)
1: 0 to +10 V (no lower limit)
0, 1 0 A A A 410 —
Switch between current or voltage
inputs by using DIP switch S1-2
switch on the terminal board.
H3-02
<22>
<22> Parameter can be changed during run.
Terminal A1 Function
Selection
Assign a function to terminal A1. When
terminal A1 is not used or is used only as a
through terminal, this parameter must be set to
“F”.
0 to 31 0 A A A 434 —
H3-03
<22>
Terminal A1 Gain
Setting
Sets the output level when 10 V is input, as a
percentage of the maximum output frequency
(E1-04).
-999.9 to
999.9
100.
0%
AAA 411 —
H3-04
<22>
Terminal A1 Bias
Setting
Sets the output level when 0 V is input, as a
percentage of the maximum output frequency
(E1-04).
-999.9 to
999.9
0.0
%
A A A 412 —
H3-09
Terminal A2 Signal
Level Selection
Sets the input signal level for terminal A2.
0: 0 to +10 V (with lower limit)
1: 0 to +10 V (no lower limit)
2: 4 to 20 mA
3: 0 to 20 mA
0 to 3 2 A A A 417 —
Switch between current or voltage
inputs by using DIP switch S1-2
switch on the terminal board. Refer
to I/O Connections on page 84.
H3-10
<22>
Terminal A2 Function
Selection
Sets the multi-function input command for
terminal A2.
When set to F, terminal A2 is not used and acts
as a through terminal.
0 to 31 0 A A A 418 —
H3-11
<22>
Terminal A2 Gain
Setting
Sets the level of the frequency reference as a
percentage of the 10 V (20 mA) input level for
the function set to H3-10.
-999.9 to
1000.0
100.
0%
A A A 419 —
H3-12
<22>
Frequency Reference
(Current) Terminal
A2 Input Bias
Sets the level of the frequency reference as a
percentage of the 0 V (4 mA) input level for
the function set to H3-10.
-999.9 to
999.-
0.0
%
A A A 41A —
H3-13
<22>
Analog Input Filter
Time Constant
Sets the primary delay filter time constant for
terminals A1 and A2.
Effective for reducing noise.
0.00 to
2.00
0.0
3 s
A A A 41B —
