ABB IRC5 User Manual

2 Installation and Commissioning, IRC5
2.8.1. Definition of I/O units, IRC5
1013HAC021313-001 Revision: K
© Copyright 2004-2008 ABB. All rights reserved.
I/O units
The table below specifies the I/O units:
Gateways
The table below specifies the Gateways:
Encoder interface units
The table below specifies the encoder interface units:
Further information
The table below gives references to additional information:
Description Note
AD Combi I/O DSQC 651
See I/O System parts on page 323 for the
spare part number
Digital I/O DSQC 652
See I/O System parts on page 323 for the
spare part number
Digital I/O with relay outputs DSQC 653
See I/O System parts on page 323 for the
spare part number
Analog ±10 V I/O DSQC 355A
See I/O System parts on page 323 for the
spare part number
Description Art. no. Note
DeviceNet/Allen Bradely Remote I/O
Gateway
3HNE00025-1 DSQC 350A
DeviceNet/Interbus Gateway 3HNE00006-1 DSQC 351A
DeviceNet/Profibus DP Gateway 3HNE00009-1 DSQC 352A
Description Art. no. Note
Encoder interface unit for conveyor
tracking
3HNE01586-1 DSQC 377A.
Information: Found in:
How to install the I/O units and
Gateways mechanically and electri-
cally.
Section Installation of I/O, Gateways and encoder
interface units, IRC5 on page 113.
Allowed configurations of I/O units
and how to setup the configurations.
Technical reference manual - System parameters
How to install the I/O unit and
Gateways software related in a new
system.
The Application manual for the different I/O buses
respectively.
Detailed descriptions of all available
I/O units and Gateways.
The Application manual for the different I/O buses
respectively.
Continued
