ABB IRC5 User Manual

Prepared by, date:
58
We reserve all rights in this document and in the information contained therein.Reproduction, use or
disclosure to third parties without express authority is strictly forbidden. © Copyright 2003 ABB
Page 57.1
153Total
3HAC024480-004
Latest revision:
Approved by, date:
PROFINET
Location:
Plant:
=
+
+
Sublocation:
CAB
CM
Document no.
Next
Rev. Ind
03
Lab/Office:
Status:
CONTROL SYS. IRC5 M2004 DESIGN 06
Approved
2008-07-17
1 2 3 4 5 6 7 8
-Z1
PCI BUS
Customer
Connection
-A33.1
PROFINET DSQC678
-X2
11
22
33
44
55
66
77
88
-X1
11
22
33
44
55
66
77
88
-X3
11
22
33
44
55
66
77
88
-LAN1
11
22
33
44
55
66
77
88
OPTION & HARNESS TO CUSTOMER I/O
TX+
TX-
RX+
RX-
TX+
TX-
RX+
RX-
TX+
TX-
RX+
RX-
TX+
TX-
RX+
RX-

ABB IRC5 Specifications

General

Type	Industrial Robot Controller
Model	IRC5
Protection Class	IP54
Power Supply	200-600 VAC, 50/60 Hz
Communication Protocols	PROFIBUS, PROFINET, DeviceNet
Programming Language	RAPID
Number of axes	Up to 36
Storage Temperature	-25°C to +55°C
Relative Humidity	95% (non-condensing)
