4 Repair activities, controller IRC5
4.15. Replacement of PCI boards in the computer unit DSQC639
2493HAC021313-001 Revision: K
© Copyright 2004-2008 ABB. All rights reserved.
4.15. Replacement of PCI boards in the computer unit DSQC639
Location
A number of boards may be fitted in the slots in the computer unit as shown in the figure
below:
Ethernet card
Interbus Master/Slave with copper interface
Interbus Master/Slave with fiber-optic interface
Profibus-DP Master/Slave
DeviceNet Master/Slave single
DeviceNet Master/Slave dual
PROFINET Master/Slave
xx0600002915
Description
A Slot for PCI cards
Continues on next page
