2 Installation and Commissioning, IRC5
2.5.7. Connecting the communication cabling for the Dual Cabinet Controller
633HAC021313-001 Revision: K
© Copyright 2004-2008 ABB. All rights reserved.
2.5.7. Connecting the communication cabling for the Dual Cabinet Controller
General
Normally the communication cabling between the Control Module and Drive Module are
installed at delivery.
The following procedures describes exceptions from the standard delivery, when the cables
must be connected to the Control Module after delivery.
Communication cabling
The communication cabling are delivered with the Drive Module, and consists of the
following cables:
Ethernet cable
Safety cable
Location
xx0600003365
A Ethernet cable
B Safety cable
Continues on next page
