2 Installation and Commissioning, IRC5
2.5.13. Connection of Drive Module Disconnect, by limit switch
793HAC021313-001 Revision: K
© Copyright 2004-2008 ABB. All rights reserved.
3. Connect the wires to the connector X22
according to the diagram on the right.
xx0500002091
