6-22 Pneumatic Subsystem
Pneumatic Subsystem Components 5DX Series 3
19. Locate the following lines and set to the positions recorded:
@Mach_LeftInnerBarrierOpen
@Mach_LeftInnerBarrierClosed
@Mach_RightInnerBarrierOpen
@Mach_RightInnerBarrierClosed
Using the information in Figure 6-15 and Figure 6-16, the values would be:
@Mach_LeftInnerBarrierOpen173
@Mach_LeftInnerBarrierClosed-165
@Mach_RightInnerBarrierOpen-182
@Mach_RightInnerBarrierClosed189
20. Press Alt-w to save the file.
21. Press Alt-x to exit.
Verify that the positions were set correctly.
1. Start the User Interface.
2. Select Utilities and press Enter.
3. Select Service Menu and press Enter.
4. Select Panel Handling and press Enter.
5. Select Hardware Control and press Enter.
6. Type 0 to set the Hardware Status and Control to output mode.
WA R N I NG Type 9 to toggle the output bit for moving the Inner Barrier. If the positions
entered in machine.cfg were incorrect with respect to the physical Encoder
counts, then DIOMON will indicate that the Inner Barrier is in an unknown
state.
