Agilent Technologies 5DX Service Guide

Agilent 5DX Service Guide 10-23
5DX Series 3 Main Cabinet Maintenance
Information:
Figure 10-8: Focus Coil Power Supply
System
Controller
Focus Coil
Power Supply
Motion Driver
Assembly
Expansion
Chassis
Low Voltage
Assembly
Digital I/O Assembly
Motion Driver
Power Supply
System Status
Beacon
X-ray Scan
Controller
DO NOT
ADJUST!
The Electronics Bay is shown
without the front door.
