STATus Subsystem 9
U2000 Series Programming Guide 231
Device Status Register Sets
The status registers contain information which give device status information.
The contents of the individual registers of these register sets may be accessed
by appending the commands listed in “Status Register Set Commands” on
page 226.
The following command descriptions detail the SCPI register you require to
control but do not detail the register set commands.
The one device status register set is:
STATus:DEVice:
The following bits in these registers are used by the power sensor:
The power sensor error bits (3) are set to:
• 1, if the U2000 Series USB power sensor’s non- volatile memory has failed.
• 0, for every other condition.
Bit Number Decimal
Weight
Definition
0 - Not used
1 2 Not used
2 4 Not used
38Power sensor error
4 16 Not used
7-15 - Not used
14 16384 Not used
15 - Bit 15 always 0
