Power Sensor Remote Operation 1
U2000 Series Programming Guide 45
Operation Status
The Operation Status group monitors conditions in the power sensor’s
measurement process.
The Operation status model is shown in the pullout at the end of this chapter.
The following bits in these registers are used by the power sensor:
Tab le 1-7 Bit Definitions - Operation Status
8CALibration
Summary
This is a summary bit for the Questionable CALibration
Register.
• SET:
These may be caused by
CALibration[1]:ZERO:AUTO ONCE or
CALibration[1]:AUTO ONCE or
CALibration[1][:ALL] or
CALibration[1][:ALL]?.
Error –231, “Data questionable; ZERO ERROR”
Error –231, “Data questionable; CAL ERROR”
• CLEARED: When any of the commands listed above
succeed and no errors are placed on the error queue.
9 Power On Self
Te s t
• SET: This bit is set when the power on self test fails.
• CLEARED: When the power on self test passes.
Bit
Number
Meaning EVENts Causing Bit Changes
Bit Number Decimal
Weight
Definition
0 1 CALibrating Summary
1 - 3 - Not used
4 16 MEASuring Summary
5 32 Waiting for TRIGger Summary
6 - 9 - Not used
10 1024 SENSe Summary
11 2048 Lower Limit Fail Summary
