Agilent Technologies U2000 Series

1 Power Sensor Remote Operation
40 U2000 Series Programming Guide
Figure 1-8 Status System
Questionable Status
Logical OR
Condition Event Enable
Operation Status
Logical OR
Condition Event Enable
Standard Event
Logical OR
Event
Enable
*ESR
*ESE
Status Byte
Logical OR
*STB?
*SRE
MAV
0
1
2
QUE
ESB
RQS/MSS
OPR
MAV
0
1
2
QUE
ESB
X
OPR
Output Queue
Device Status
Logical OR
Condition Event Enable
Error/Event Queue
