STATus Subsystem 9
U2000 Series Programming Guide 235
STATus:OPERation:LLFail[:SUMMary]
The operation status lower limit fail summary register set contains
information on the lower limit fail status of the power sensor.
The following bits in these registers are used by the power sensor:
The appropriate bits are set if a channel lower limit test fails or a window
lower limit test fails.
These bits are cleared if a measurement is made and the test is enabled and
passes.
Syntax
Bit
Number
Decimal
Weight
Definition
0 - Not used
1 2 Current window LLFail Status
2 4 Not used
3 8 Not used
4 16 Not used
5 32 Not used
6 64 Not used
7-15 - Not used
