Device Status Register
The device status register set contains bits which give device dependent
information.
The following bits in these registers are used by the power sensor:
Tab le 1-9 Bit Definitions - Device Status Register
The condition bits are set and cleared under the following conditions:
12 Upper Limit
Fail
This is a summary bit for the Upper Limit Fail Register.
• SET: If a measurement is made and upper limit test fails.
• CLEARED: If a measurement is made and the upper limit test is not enabled or
the test is enabled and passes.
Bit
Number
Meaning EVENts Causing Bit Changes
Bit
Number
Decimal
Weight
Definition
0 - Not used
1 2 Not used
2 4 Not used
3 8 Power sensor error
416
Not used
5 32 Not used
664
Not used
14 16384 Not used
