MEASurement Commands 2
U2000 Series Programming Guide 81
MEASure[1][:SCALar][:POWer:AC]?
[<expected_value>[,<resolution>[,<source list>]]]
This command sets the current window’s measurement function with relative
mode off, aborts, configures the window, calculates the measurement result
and places the result on the bus.
Syntax
Parameters
Refer to “Optional Parameters” on page 67 for additional details on the
parameters in this command.
Item Description/Default Range of Values
expected_value
(for the expected
power level)
A numeric value for the expected power level.
The units of measurement are dBm and W.
The default units are defined by
UNIT:POWer.
–60 dBm to +20 dBm
DEF
1
resolution A numeric value for the resolution. If
unspecified the current resolution setting is
used.
1 to 4
2
1.0, 0.1, 0.01, 0.001
DEF
1
