Power Sensor Remote Operation 1
U2000 Series Programming Guide 7
Making Measurement
The MEASure? and CONFigure commands provide a straight- forward method
to program the power sensor for measurements. You can select the
measurement’s expected power level and resolution all in one command. The
power sensor automatically presets other measurement parameters to default
values as shown in Table 1- 1 below.
Tab le 1-1 MEASure? and CONFigure Preset States
An alternative method to program the power sensor is to use the lower level
commands. The advantage of using the lower level commands over the
CONFigure command is that they give you more precise control of the power
sensor. As shown in Table 1- 1, the CONFigure command presets various
states in the power sensor. It may be likely that you do not want to preset
these states. Refer to “Using the Lower Level Commands” on page 15 for
further information.
Command MEASure? and CONFigure Setting
Trigger source
(TRIGger:SOURce)
Immediate
Filter
([SENSe[1]]:AVERage:COUNt:AU
TO)
On
Filter
state([SENSe[1]]:AVERage:STATe
)
On
Trigger cycle
(INITiate:CONTinuous)
Off
TriggerDelay
(TRIGger:DELay:AUTO)
On
