10 SYSTem Subsystem
258 U2000 Series Programming Guide
Preset Values
DEFault
Table 10- 1 shows the power sensor presets when <character_data> is set to
DEFault or omitted. Values are shown for all SCPI commands:
Tab le 10-1 DEFault: Power Sensor Presets
Command Setting Comments
CALC[1]:FEED[1] “POW:AVER” Select average measurement type
CALC[1]:LIM:CLE:AUTO ON Clear limit data at INIT
CALC[1]:LIM:LOW[:DATA] –90 dBm Lower limit
CALC[1]:LIM:STAT OFF Window limits checking disabled
CALC[1]:LIM:UPP[:DATA] +90 dBm
CALC[1]:MATH[:EXPR] Upper
Lower
Math expression
FORM[:READ]:BORD normal Binary order
FORM[:READ][:DATA] ascii Data format
INIT[1]:CONT *RST: OFF
SYS:PRES ON
Power Sensor in idle state
Power Sensor in wait for trigger
state
MEM:TABL:SEL not affected Active sensor calibration table
[SENSe[1]]:AVER:COUN 4 Filter length
[SENSe[1]]:AVER:COUN:AUTO ON Auto-filtering enabled
[SENSe[1]]:AVER:SDET 1 Step detection enabled
[SENSe[1]]:AVER[:STAT] ON Averaging enabled
[SENSe[1]]:CORR:CSET[2][:SEL] not affected Selected frequency dependent offset
table
[SENSe[1]]:CORR:CSET[2]:STAT not affected Sensor frequency dependent offset
disabled
[SENSe[1]]:CORR:FDOF|GAIN4[:INP][:
MAGN]
not affected Return frequency dependent offset
[SENSe[1]]:CORR:GAIN2:STAT OFF Channel offset disabled
[SENSe[1]]:CORR:GAIN2:STAT
[:INPut][:MAGNitude]
0.0 dB Enter channel offset value
