• ASCII Flex Protocol QUICKDESIGNER
These are limited only by the amount of memory available. Later in this document I will provide a
Formula for calculating the amount of memory used.
Memory Used Status Bar
This indicator is shown on 3 of the Flex dialogs. It represents the percentage of memory used by the
project. Whenever you take an action which pushes the memory used over 100%, an error message is
displayed indicating this problem and giving you suggestions on how to gain more project memory.
The worst case scenario is you will have to Cancel out of the New Sequence dialog or remove
Associations. The current memory limit is 16384 bytes.
Setup Options
Parameter Scale Range Default Have to
Fill in
Poll Delay
Milliseconds 0 - 10000 0 No
Reply Time Out
Seconds 0 - 60 3 No
Send Delay
Milliseconds 0 - 10000 0 No
Prompt Char(s)
Characters Up to 5 Printable
characters
None No
End of Packet
Char (Rcv only)
Characters Any character 13
(CR)
Yes
Initialization
Sequence
Label Any Valid
Sequence
None No
Does Controller
Echo Commands -
Y/N Y/N Y No
Does Controller
Echo XON/XOFF
Y/N Y/N Y No
Generate Error
Code for Invalid
Message
Y/N Y/N Y No
Invalid Message
Destination
DM type Valid DM for
a string type
None No
Error Message
Destination
DM Type Valid DM for
a string type
None No
