QUICKDESIGNER Keyence Port 1 •
••
• 143
Keyence Port 1
Keyence KV-L2
CAUTION
Do NOT use this protocol with QP1 devices. It is designed to be used with
ONLY QP2 devices. For example, QPJ-2D100-L2P is a QP2 device.
Tag Variable Table
Name Address rangeValue range Writeable Type
W 0-69 0-65535 Y integer
WT 0-249 0-65535 N integer
WC 0-249 0-65535 N integer
DM 0-8999 0-65535 Y integer
TM 0-31 0-65535 Y integer
abb 000-6915 0-1 Y integer
T 0-249 0-1 Y bit
C 0-249 0-1 Y bit
DMa.bb 0-15 0-1 Y bit
TMa.bb 0-15 0-1 N bit
Note: The format abb and a.bb the a represents the address, and bb represents two digits bits. For
example: for format abb, you must type at least one digit for the address and the two last digits
represents the bits, i.e. 000 represents in address 0 bit 00; for format a.bb, you must type the address,
then the ., and after that two digits to represents the bits, i.e. DM0.00 represents address 0 bit 00.
CONFIGURATION
Keyence KV-L2 - Setup the Quick Panel to RS232C, 19200 baud, 8 data bits, even parity, 1 stop bit,
and none handshake. Click on Protocol and for PLC Station No., type 0. Connect the HMI-CAB-C53
cable between the I/O port on the Quick Panel and Port 1 on the PLC.
Verify the following settings for the switches in one side of the PLC: Interface Switch, select 232C.
For Terminator Switch, select OFF. For Station No. Switch, select 0. For Set A Switches: Switches 2
and 4 - ON, Switches 1 and 3 - OFF. For Set B Switches: Switches 3, 4, 5 and 6 - ON, Switches 1, 2,
7 and 8 - OFF.
