Connecting a target display to a Toshiba T2 PLC
The connection is RS-485. Connect the HMI-CAB-C97 cable to the LINK port.
QUICKPANEL jr.
TOSHIBA T2
TO TOSHIBA T2
PROGRAM PORT
TO TCP DEVICE
HMI-CAB-C97
0
1
2
3
4
5
6
7
8
9
TOSHIBA
PU224
T2
RUN
FAUL T
I/O
BATT
ROM
HALT P-RUN
RUN
PROG
LINK
FG
LG
N
110 L
NC
NC
RUN
24Vdc
OUT
OUT
BATT
01234567
89ABCDEF
01234567
89 AB CDEF
HMI-CAB-C97 Cable
Use the following diagram to construct your own cable.
TO TOSHIBA T2
TO TCP DEVICE
HMI-CAB-C97
TO TCP DEVICE
TO PLC PORT
SHIELD
11
3
5
7
7
4
8
15
25 PIN MALE
15 PIN MALE
1
5
16
10
4
10
2
RESISTOR
120 OHM-.5W
RESISTOR
120 OHM-.5W
11
15
18
19
21
22
12
13
Setup for using Toshiba PLCs
Use the following procedure to ensure your target device is setup properly for the Toshiba PLC. The
procedure is in condensed format. Only the required settings are outlined. For additional details, see
Creating a New Project beginning on page 3.
