Allen-Bradley SLC 500

26 •
••
• Allen-Bradley QUICKDESIGNER
Example Configurations
This first example shows a 3-Node network (not expandable). The QuickPanel is connected to the DH-
485 network on the AIC Port 3 using the HMI-CAB-C117 cable.
19200
14400
9600
4800
2400
1200
600
AUTO
TX TX
TX PWR
AIC+
QUICKPANEL
1761-CBL-AM00
OR
1761-CBL-HM02
1747-CP3
OR
1761-CBL-AC00
HMI-CAB-C117
PORT 2
MINI-DIN 8 RS-232
PORT 1
DB-9 RS-232, DTE
PORT 3 DH485/DF1
MASTER-SLAVE
MicroLogix
