118 •
••
• GE GENIUS QUICKDESIGNER
Press F1 (gbc) and then the Enter key to select the GBC. The following screen will appear. (Note that
the defalt softkey, F9, is inactive for the GBC module.)
SLOT
3
RACK
1
gbc
2 3 4 5 6 7 8 9 10
>
gcm def al t
C:\ LM90\SYSTEM3
REPLACE
OFF LI N E
PRG: SYSTEM3
CONFIG VALID
SERIES 90-30 MODULE IN RACK
0 3
SLOT
Catalog #:
SOFTWARE CONFIGURATION
CATALOG # DESCRIPTION
TYPE
1 IC693BEM331 9030 GENIUS BUS CONTROLLER GBC
< < CURSOR TO THE DESIRED CATALOG NUMBER AND PRESS THE ENTER KEY > >
< < PRESS PGDN KEY FOR NEXT PAGE, PGUP KEY FOR PREVIOUS PAGE > >
Press the Enter key to select the GBC. Complete the GBC configuration entries in the following screen.
SLOT
3
RACK
1
gbc
2 3 4 5 6 7 8 9 10
>
gcm def al t
C:\ LM90\SYSTEM3
REPLACE
OFF LI N E
PRG: SYSTEM3
CONFIG VALID
SERIES 90-30 MODULE IN RACK
0 3
SLOT
Catalog #:
SOFTWARE CONFIGURATION
BUS CONTROLLER MODULE DATA
< < More Devices Exist; PgDn for Next Device. PgUp for Previous Device > >
BEM331
GBC
IC693BEM331
9030 GENI US BUS CONTROLLER
%I,%Q,%G lengths are bits; %AI,%AQ,%R are words
Module SBA : 31
S6 Ref : 0
Device SBA : 0
Device Type : GENERIC
Baud Rate : 153K EXT
Status : %I0001
Input1 Ref : %I0033
Input2 Ref : %AI0001
Output1 Ref : %Q0001
Output2 Ref : %AQ001
Input1 Len : 0
Output1 Len : 0
Input2 Len : 0
Output2 Len : 0
Input Def : OFF
Out at strt : ENABLED
Note that the configuration screen consists of two parts: module-specific data (BUS CONTROLLER
MODULE DATA) and device-specific data (DEVICE DATA).
Until a valid configuration is stored to the PLC CPU, the GBC will not operate on the bus, and its
Channel OK LED will not light.
Module-specific Data
Module SBA (serial bus address)
Ordinarily, the Device Number (bus address) assigned to a bus controller is 31. Any number from 0 to
31 can be used; however, each must be unique on that Genius bus (no configured device already
present at that address). Whenever a Module SBA value is changed to a new value, the DEVICE
DATA for the GBC associated with the old address is automatically copied to the new address value
and cleared from the old address. Default: 31
