Toyopuc-2
TOYOPUC PC2F
CAUTION
Do NOT use this protocol with QP1 devices. It is designed to be used with
ONLY QP2 devices. For example, QPJ-2D100-L2P is a QP2 device.
Tag Variable Table
Name Address range Value range Writeable Type
XaaW 0-7F 0-65535 Y integer
YaaW 0-7F 0-65535 Y integer
MaaW 0-7F 0-65535 Y integer
KaaW 0-2F 0-65535 Y integer
LaaW 0-7F 0-65535 Y integer
VaW 0-F 0-65535 Y integer
N 0-1FF 0-65535 Y integer
D 0-2FFF 0-65535 Y integer
R 0-7FF 0-65535 Y integer
B 0-1FFF 0-65535 Y integer
S 0-3FF 0-65535 Y integer
Xaab 0-7FF 0-1 Y integer
Yaab 0-7FF 0-1 Y integer
Maab 0-7FF 0-1 Y integer
Kaab 0-2FF 0-1 Y integer
Laab 0-7FF 0-1 Y integer
Vab 0-FF 0-1 Y integer
Paab 0-1FF 0-1 Y integer
T 0-1FF 0-1 Y integer
C 0-1FF 0-1 Y integer
CONFIGURATION
Toyopuc PC2 - Setup the Quick Panel to RS422/485 Half Duplex, 19200 baud, 8 data bits, even
parity, 1 stop bit, and none handshake. Click on Protocol and set the PLC Station No. to 0.
Verify the following Switch Settings in the PLC: L0 Switches, for ST. NO. HI. set 0, ST. NO. HI. set to
0, BAUD RATE set to 1; L2 Switches, for ST. NO. HI. set 0, ST. NO. LO. set to 1, BAUD RATE set
to 2.
