Keyence Program Port
Keyence KV-L2, KV-10R
CAUTION
Do NOT use this protocol with QP1 devices. It is designed to be used with
ONLY QP2 devices. For example, QPJ-2D100-L2P is a QP2 device.
Tag Variable Table
Tag Name Address Bit Range Value Type Read Example Description & Notes
Format Range Range Write
WTaaaa 0 - 9999 None 0 - 65535 Integer Read WT20 Timer Current Value
WCaaaa 0 - 9999 None 0 - 65535 Integer Read WC022 Counter Current Value
DMaaaa 0 - 9999 None 0 - 65535 Integer R/W DM1 Data Memory
TMaaaa 0 - 9999 None 0 - 65535 Integer R/W TM1 Temp Data Memory
aaaabb 0 - 9999 00 - 15 0 - 1 Bit R/W 500 Input, Output, Utility, Internal,
Special
Taaaa 0 - 9999 None 0 - 1 Bit R/W T20 Timer Contact
Caaaa 0 - 9999 None 0 - 1 Bit R/W C22 Counter Contact
DMaaaa.bb 0 - 9999 00 - 15 0 - 1 Bit R/W DM1.1 Data Memory
TMaaaa.bb 0 - 9999 00 - 15 0 - 1 Bit Read TM1.1 Temp Data Memory
Note: The format abb and a.bb the a represents the address, and bb represents two digits bits. For
example: for format abb, you must type at least one digit for the address and the two last digits
represents the bits, i.e. 000 represents in address 0 bit 00; for format a.bb, you must type the address,
then the (. ), and after that two digits to represents the bits, i.e. DM0. 00 represents address 0 bit 00.
Note: For DMaaaa, registers 9000-9827 are special purpose.
CONFIGURATION
Keyence KV-10R - Setup the Quick Panel to RS232C, 9600 baud, 8 data bits, even parity, 1 stop bit,
and none handshake. Connect the cable between the I/O port on the Quick Panel and the programming
port on the PLC.
Keyence KV-L2 - Setup the Quick Panel to RS232C, 9600 baud, 8 data bits, even parity, 1 stop bit,
and none handshake. Connect the cable between the I/O port on the Quick Panel and Port 1 on the
PLC. Verify the following settings for the switches in one side of the PLC: Interface Switch, select
232C. For Terminator Switch, select OFF. For Station No. Switch, select 0. For Set A Switches:
Switches 2 and 4 - ON, Switches 1 and 3 - OFF. For Set B Switches: Switches 3, 4, 5 and 6 - ON,
Switches 1, 2, 7 and 8 - OFF.
