• GE GENIUS QUICKDESIGNER
Device Type (QuickPanel)
Each device is associated with a device type. The device type selection can be tabbed through. Default:
GENERIC
For a device to receive global data, configure it as GENERIC and specify memory type and length for
the incoming data. Up to 128 bytes can be configured for the total of Input1 Length. Discrete(%I) data
will automatically be adjusted to multiples of 8 for byte alignment. Use only one input.
SLOT
3
RACK
1
gbc
2 3 4 5 6 7 8 9 10
>
gcm def al t
C:\ LM90\SYSTEM3
REPLACE
OFF LI N E
PRG: SYSTEM3
CONFIG VALID
SERIES 90-30 MODULE IN RACK
0 3
SLOT
Catalog #:
SOFTWARE CONFIGURATION
BUS CONTROLLER MODULE DATA
< < More Devices Exist; PgDn for Next Device. PgUp for Previous Device > >
BEM331
GBC
IC693BEM331
9030 GENI US BUS CONTROLLER
%I,%Q,%G lengths are bits; %AI,%AQ,%R are words
Module SBA : 31
S6 Ref : 0
Device SBA : 21
Device Type :
Baud Rate : 153K EXT
Status : %I0001
Input1 Ref : %I0033
Input2 Ref : N/A
Output1 Ref : N/A
Output2 Ref : N/A
Input1 Len : 0
Output1 Len : N/A
Input2 Len : N/A
Output2 Len : N/A
Input Def : OFF
Out at strt : ENABLED
8%I
GENERIC Devices
Note: For Input and Output Ref, the allowed memory types are %I, %AI, %Q, %AQ, %G, and %R.
Inputl Ref, Inputl Length
A GENERIC device can be configured with two independent starting locations for input data with
associated lengths for each location. The input data received from the device by the GBC is extracted
and deposited into the PLC memory areas starting at these specified locations. Default: next available
%I reference
Input2 Ref, Input2 Length (Not used for QuickPanel)
Outputl Ref, Outputl Length (Not used for QuickPanel)
Output2 Ref, Output2 Length (Not used for QuickPanel)
