256 •
••
• ASCII Protocol QUICKDESIGNER
Protocol Button
Click the Protocol button to display the ASCII Single Drop dialog box. The timeout shown works for
most applications.
System Button
Make sure you select QPJ-1 or QPJ-2 for compilation. For more information about creating a new
project and configuring the display, see page 3. Please note that some features are available only on the
QP2.
Panel Design
For this example, a panel has been created that contains many of the common panel tools. The
following picture shows what the panel looks like on a QuickPanel jr.
As you create each panel component, a dialog box will ask the name of the TAG. The tag names have a
specific naming format for the ASCII protocol.
