• Hitachi H Series QUICKDESIGNER
Hitachi H Series
Hitachi H Series
CAUTION
Do NOT use this protocol with QP1 devices. It is designed to be used with
ONLY QP2 devices. For example, QPJ-2D100-L2P is a QP2 device.
Cabling:
The following chart shows the point-to-point wiring for the interface cable. The QuickPanel end uses a
25 pin male connector while the Hitachi PLC end uses a 15 pin male.
QuickPanel (25 pin Male) 96MFM20AA (15 pin Male)
TXD 2 3 RD
RXD 3 2 SD
CTS 5 4 RS
GND 7 9 SG
DTR 20 5 CS
8PHL
7DR
14 19200 BAUD
Comm Settings:
19200, 7, 1, E, RS232
