Model 560/565 "S" Register Names
The following "S" register variables are available for reading and writing, except where noted.
Registers shown in the 'Real Only' column are from -99999999 to 99999999. Registers shown in the
'Integer Only' column are from -32767 to 32767.
Real Only Integer Only
AADB AADBI
ACFH, ACFL
AERR AERRI
(1)
AHA, AHHA AHAI, AHHAI
ALA, ALLA ALAI, ALLAI
AODA AODAI
APV APVI
APVH, APVL
ARCA
ASP ASPI
ASPH, ASPL ASPHI, ASPLI
ATS AVF
AYDA AYDAI
DCP/DCC
KF K
(1)
LADB LADBI
LCFH, LCFL
LERR LERRI
(1)
LHA, LHHA LHAI, LHHAI
LKC
LLA, LLLA LLAI, LLLAI
LMN, LMX LMNI, LMXI
LODA LODAI
LPV LPVI
LPVH, LPVL
LRCA LRSF
LSP LSPI
LSPH, LSPL LSPHI, LSPLI
LTD, LTI, LTS LVF
LYDA LYDAI
STW
(1)
TTI
TCP/TCC
VF WXI
(1)
WYI
V
WX, WY
DSP/DSC (2)
(1)
READ ONLY
(2)
Range value = 0 to 15
