Allen-Bradley SLC 500

70 •
••
• Aromat QUICKDESIGNER
Cable
This cable connects to a FP1 Smart Cable P/N AFP15201-US9. The FP1 Smart Cable can be obtained
from Aromat.
TO PLC PORT
3
2
5
25 PIN MALE
HMI-CAB-C111
TO PLC PORTTO TCP DEVICE
9 PIN MALE
7
3
2
4
5
TO TCP DEVICE
1
Shield
