• ASCII Protocol QUICKDESIGNER
Error Messages
Error messages appear on the bottom of the QP2 display. Errors encountered with QP1 are ignored and
the message is discarded.
Error Messages Meaning
PLC COM. ERROR(02: D0 ) Month out of Range
PLC COM. ERROR(02: D1 ) The month was not sent when sending the date
PLC COM. ERROR(02: D2 ) Day Out Of Range
PLC COM. ERROR(02: D3 ) The day was not sent when sending the date
PLC COM. ERROR(02: D4 ) Year out of Range
PLC COM. ERROR(02: D5 ) The year was not sent when send the date
PLC COM. ERROR(02: D6 ) Hour out of Range
PLC COM. ERROR(02: D7 ) The hour was not sent when sending the date
PLC COM. ERROR(02: D8 ) Minutes out of range
PLC COM. ERROR(02: D9 ) The minutes were not sent when sending the date
PLC COM. ERROR(02: DA ) A long invalid packet was sent
PLC COM. ERROR(02: DB ) The trigger command was trying to access screen 0
PLC COM. ERROR(02: DC ) The screen number was not sent with the trigger command
PLC COM. ERROR(02: DD ) An incomplete write command was sent
PLC COM. ERROR(02: DE ) The first field in the read command was not numeric or was 0
PLC COM. ERROR(02: DF ) A read was issued for data that does not exist and the count was
less then 1 or not numeric
PLC COM. ERROR(02: F0 ) A read Was issued for data that does not exist and the count was
not specified
PLC COM. ERROR(02: F1 ) Internal Error - Getting semaphore to set the date
PLC COM. ERROR(02: F2 ) Internal Error - Getting the second semaphore to set the date
PLC COM. ERROR(02: F3 ) Internal Error - Binary Search Failed
PLC COM. ERROR(02: F4 ) Internal Error - Allocating Memory for the DM table
PLC COM. ERROR(02: F5 ) Internal Error - There was more then 10k words to allocate for
the DM table
PLC COM. ERROR(02: F6 ) The packet received was to large.
PLC COM. ERROR(02: F7 ) The communication time-out
