Allen-Bradley SLC 500

QUICKDESIGNER Mitsubishi •
••
• 151
Mitsubishi FX Series
Connecting to a Mitsubishi FX
QUICKPANEL jr.
TO MITSUBISHI
PROGRAM PORT
TO TCP DEVICE
HMI-CAB-C91
POWER
RUN
BATT.V
PROS-E / CPU-E
FX-16MR
MITSUBI SHI
MITSUBISHI FX
HMI-CAB-C91/B Cable
7
7
TO TCP DEVICE
TO PLC PORT
HMI-CAB-C91/B
25 PIN MALE
25 PIN MALE
TO TCP DEVICE
TO PLC PORT
10
11
15
16
18
19
21
22
3
2
15
16
18
17
5
4
20
21
SHIELD
1
8
GND
RXA+
TX+
TX-
RX-
DTRB
CTSA
DTRA
CTSB
RX+
TX+
TX-
RX-
The Mitsubishi FX ON has a mini DIN connector for the program port. The Mitsubishi FX20PCADP
converter is a mini DIN to 25-pin D adapter. Use this adapter with the HMI-CAB-C91 cable to connect
to the program port.
Setup for using a Mitsubishi FX PLC
Use the following procedure to ensure your target device is setup properly for the Mitsubishi FX PLC.
The procedure is in condensed format. Only the required settings are outlined. For additional details,
see Creating a New Project beginning on page 3.
