Allen-Bradley SLC 500

28 •
••
• Allen-Bradley QUICKDESIGNER
HMI-CAB-C117 Cable
The AIC+ can connect a QuickPanel through the Port 3 DH-485/DF1 Phoenix Plug using the HMI-
CAB-C117 cable.
TO AIC+
TO TCP DEVICE
HMI-CAB-C117
TO TCP DEVICE
1
25 PIN MALE
10
7
11
15
To Terminal B
To Terminal A
16
To Terminal COM
To Terminal SHIELD
5
4
18
19
21
22
TO AIC+ PORT 3
RED
BLK
GRN
SHL
