Allen-Bradley SLC 500 Manual

14 •
••
• Allen-Bradley QUICKDESIGNER
HMI-CAB-C84 Cable
This cable connects the target display serial port to the Allen-Bradley SLC 500 Programming Port. The
cable is designed to allow connection to additional devices such as an Allen-Bradley 1747-PIC
Interface Converter.
Warning: The maximum length of this cable is 6 feet. Do not attempt to make it longer.
25-PIN MALE
8-PIN MODULAR PHONE(FEMALE)
HMI-CAB-C84/A
8-PIN MODULAR PHONE(MALE)
RJ-45
TOP
25-pin male D
RS232
TO
RS422
CIRCUIT
BOARD
shield
red
black
green
orange
blue
white
brown
-6
-1 (+)
-2 ( - )
-7 (G)
-8
-5 (E)
-4
-3
shield
red
black
green
orange
blue
white
brown
-6
-1
-2
-7
-8
-5
-4
-3
8-PIN MODULAR
PHONE JACK
8-PIN MODULAR
PHONE PLUG
CABLE LENGTH = 6'
CABLE LENGTH = 1'
PROPRIETARY INFORMATION
THIS INFORMATION IS PROVIDED AS A CONVENIENCE
TO OUR CUSTOMERS. YOU ARE NOT AUTHORIZED TO
CONSTRUCT THIS CABLE. UNAUTHORIZED CABLES ARE
NOT SUPPORTED BY TOTAL CONTROL.
THE RS232 CONVERTER CIRCUITS ARE CONTAINED ON
A CIRCUIT BOARD WITHIN THE 25-PIN D-SHELL. THE
ELECTRONIC CIRCUIT PROVIDES NETWORK CONTROL.
THE CIRCUIT DIAGRAM IS PROPRIETARY INFORMATION.
THE CABLE IS LICENSED FROM ALLEN-BRADLEY.
SLC 500 Network Connection using 1747 AIC Link Couplers (DH485)

Allen-Bradley SLC 500 Specifications

General

Programming Software	RSLogix 500
Communication Ports	RS-232, DH-485, DH+
Power Supply	120/240V AC or 24V DC
Programming Languages	Ladder Logic
Operating Temperature	0°C to 60°C (32°F to 140°F)
Relative Humidity	5% to 95% (non-condensing)
Memory	4K to 64K words (depending on the processor)
