• GE Fanuc SNP QUICKDESIGNER
GE 90-30 CMM Module
Use the HMI-CAB-C53 RS232 cable to connect a target display to a GE 90-30 CMM Module RS232
port.
HMI-CAB-C53/A
TO TCP DEVICE
TO PLC PORT
SHIELD
1
3
4
5
7
2
3
4
5
7
25 PIN MALE
TO PLC PORTTO TCP DEVICE
2
6
25 PIN MALE
8
20
Use the HMI-CAB-C93 RS485 cable to connect a target display to a GE 90-30 CMM Module RS485
port.
HMI-CAB-C93
TO TCP DEVICE
TO PLC PORT
9
7
16
7
TO PLC PORTTO TCP DEVICE
25 PIN MALE
RESISTOR
120 OHM
10
21
25
13
15
11
SHIELD1
10
11
22
23
4
5
18
19
21
22
RESISTOR
120 OHM
25 PIN MALE
