QUICKDESIGNER Hitachi H Series •
••
• 123
Tag Variables:
Variable Type Address Range Data Range
External Bit Input X00000 - X05A95
(1)
0 - 1
External Bit Output Y00000 - Y05A95
(1)
0 - 1
Remote Input Relay X10000 - X49995 0 - 1
Remote Output Relay Y10000 - Y49995 0 - 1
Internal Bit Output R000 - R7BF 0 - 1
Bit CPU Link Area 1 L0000 - L3FFF 0 - 1
Bit CPU Link Area 2 L10000 - L13FFF 0 - 1
Internal Coil M0000 - M3FFF 0 - 1
On Delay Timer TD000 -TD255 0 - 1
Single Shot Timer SS000 - SS255 0 - 1
Watch Dog Timer WDT000 - WDT255 0 - 1
Monostable Timer MS000 - MS255 0 - 1
Accumulation Timer TMR000 - TMR255 0 - 1
Up Counter CU000 - CU511 0 - 1
Ring Counter RCU000 - RCU511 0 - 1
Up/Down Counter CT000 - CT511 0 - 1
External Word Input WX0000 - WX05A7
(2)
0 - 65535
External Word Output WY0000 - WY05A7
(2)
0 - 65535
Remote Input Relay WX1000 - WX4997 0 - 65535
Remote Output Relay WY1000 - WY4997 0 - 65535
Internal Word Register WR0000 - WRC3FF 0 - 65535
Word CPU Link Area 1 WL000 - WL3FF 0 - 65535
Word CPU Link Area 2 WL1000 - WL13FF 0 - 65535
Internal Coil Word WM000 - WM3FF 0 - 65535
Timer/Counter Accumulator TC000 - TC511 0 - 65535
Note 1: Bit Device
X01234
Bit No. in Module
Slot No.
Unit No.
Note 2: Word Device
X01234
Word No. in Module
Slot No.
Unit No.
To access the bit, add the bit number to the word address. For example, the first bit of WR0100 would
be WR0100/00.
WR0100/00
Bit deviceWord device
