• PLC Direct QUICKDESIGNER
Address Format = Octal
The bit delimiter for V words is ( . ). The bit range is 0-15. The bit format is D (decimal). Other
variable types do NOT use bit delimiter.
The bit format for V, GX, X, Y, C, S, T, CT, and SP types is D (decimal)
The node ID delimiter for all types is ( _ ) . This is an underscore symbol. The Minimum Node ID is 1,
the Max Node ID is 90. The Node ID format is D (decimal).
