Allen-Bradley SLC 500

QUICKDESIGNER Siemens •
••
• 211
HMI-CAB-C92
The HMI-CAB-C92 is a 9-pin male RS-422 cable.
HMI-CAB-C100
The HMI-CAB-C100 is a 9-pin female RS-422 cable for the TI545-1102 Series.
TO TCP DEVICE
TO PLC PORT
SHIELD
1
10
9
3
25 PIN MALE
HMI-CAB-C100
TO PLC PORTTO TCP DEVICE
9 PIN FEMALE
11
8
2
15
16
18
19
4
5
21
22
HMI-CAB-C101
The HMI-CAB-C100 is a 9-pin male RS-232 cable.
TO TCP DEVICE
TO PLC PORT
SHIELD
1
3
4
5
7
2
3
5
25 PIN MALE
HMI-CAB-C101
TO PLC PORTTO TCP DEVICE
9 PIN FEMALE
2
6
4
7
8
1
TI 545 RS232 Port 2
For those interested in using RS232 to Port 2 of a TI545, use an HMI-CAB-C101 cable shown above
with a minor change. Move the jumper from pins 4 and 6 and move it to pins 5 and 6.
