Allen-Bradley SLC 500

QUICKDESIGNER GE GENIUS •
••
• 109
Device Address Range Data Range Write Description & Notes
Prefix Min./Max. Min./Max.
%RA 1-65536 0 - 65535 Yes Register ASCII
%RBT
(1)
1-65536 0 - 1 No Register Bit
%RBD4 1-65536 0 - 9999 Yes Register BCD
%RI 1-65536 -32768 to 32767 Yes Register Integer
%RUI 1-65536 0 - 65535 Yes Register Unsigned Integer
%RLI
(2)
1-65535 -99999999 to 99999999 Yes Register Long Integer
%RLUI
(2)
1-65535 0 - 99999999 Yes Register Long Unsigned Integer
%RR
(2)
1-65535 -99999999 to 99999999 Yes Register Real
%AII 1-65536 -32768 to 32767 Yes Analog Input Integer
%AIUI 1-65536 0 - 65535 Yes Analog Input Unsigned Integer
%AIR
(2)
1-65535 -99999999 to 99999999 Yes Analog Input Real
%AQI 1-65536 -32768 to 32767 No Analog Output Integer
%AQUI 1-65536 0 - 65535 No Analog Output Unsigned Integer
%AQR
(2)
1-65535 -99999999 to 99999999 No Analog Output Real
%IBY 1-8192 0 - 255 Yes Discrete Input Byte
%IBI 1-65536 0 - 1 Yes Discrete Input Bit
%QBY 1-8192 0 - 255 No Discrete Output Byte
%QBI 1-65536 0 - 1 No Discrete Output Bit
%TBY 1-8192 0 - 255 Yes Temporary Byte
%TBI 1-65536 0 - 1 Yes Temporary Bit
%MBY 1-8192 0 - 255 Yes Internal Byte
%MBI 1-65536 0 - 1 Yes Internal Bit
%SXBY 1-512 0 - 255 No Discrete System Register Byte
%SXBI 1-4096 0 - 1 No Discrete System Register Bit
%SABY 1-512 0 - 255 No Discrete System Register A Byte
%SABI 1-4096 0 - 1 No Discrete System Register A Bit
%SBBY 1-512 0 - 255 No Discrete System Register B Byte
%SBBI 1-4096 0 - 1 No Discrete System Register B Bit
%SCBY 1-512 0 - 255 No Discrete System Register C Byte
%SCBI 1-4096 0 - 1 No Discrete System Register C Bit
%GBY 1-8192 0 - 255 Yes Global Byte
%GBI 1-65536 0 - 1 Yes Global Bit
Note 1: Bit specification required
Note 2: Uses 2 registers
