Allen-Bradley SLC 500

130 •
••
• IDEC QUICKDESIGNER
Protocol Button
Click the Protocol button to display the dialog box associated with the selected PLC.
Check the Enable Network box if the display is connected to a network device. Enter the Destination
ID. Enter Timeout in seconds.
Click OK to return to the Project Setup dialog box.
