• Toshiba QUICKDESIGNER
Toshiba Tag Variable Table
Name Address
Range
Bit suffix
Range
Writes
supported
Value Range
**
Sample(s) Notes:
X
EX/M: 0 - 31
T1: T.B.A.
T2: 0 - 63
T3: 0 - 255
0 - F yes 0 or 1 X12 The last digit of the
address indicates the
desired bit
XWA
or
XWA:U
EX/M: 0 - 63
T1: T.B.A.
T2: 0 - 63
T3: 0 - 255
N.A. yes 0 -
65535
XW27 Unsigned integer default
format
Y
EX/M: 0 - 31
T1: T.B.A.
T2: 0 - 63
T3: 0 - 255
0 - F yes 0 or 1 Y34F_14 The last digit of the
address indicates the
desired bit
YWA
or
YWA:U
EX/M: 0 - 63
T1: T.B.A.
T2: 0 - 63
T3: 0 - 255
N.A. yes 0 -
65535
YW56 Unsigned integer default
format
R
EX/M: 0 - 63
T1:T.B.A.
T2: 0 - 127
T3: 0 - 511
0 - F yes
0 or 1
R457 The last digit of the
address indicates the
desired bit
RWA
or
RWA:U
EX/M: 0 - 63
T1:T.B.A.
T2: 0 - 127
T3: 0 - 511
N.A. yes 0 -
65535
R63 Unsigned integer default
format
L
EX/M: N.A.
T1:T.B.A.
T2: 0 - 255
T3: 0 - 255
0 - F yes 0 or 1 L346 The last digit of the
address indicates the
desired bit
LWA
or
LWA:U
EX/M: N.A.
T1:T.B.A.
T2: 0 - 255
T3: 0 - 255
N.A. yes 0 -
65535
LW56 Unsigned integer default
format
Z
EX/M: 0 -31
T1:T.B.A.
T2: 0 - 511
T3: 0 - 511
0 - F yes 0 or 1 Z238 The last digit of the
address indicates the
desired bit
ZWA
or
ZWA:U
EX/M: 0 -31
T1:T.B.A.
T2: 0 - 1023
T3: 0 - 1023
N.A. yes 0 -
65535
ZW245 Unsigned integer default
format
S
EX/M: N.A.
T1:T.B.A.
T2: 0 - 255
T3: 0 - 255
0 - F yes 0 or 1 S254F The last digit of the
address indicates the
desired bit
SWA
or
SWA:U
EX/M: N.A.
T1:T.B.A.
T2: 0 - 255
T3: 0 - 255
N.A. yes 0 -
65535
SW5 Unsigned integer default
format
TA
or
TA:U
EX/M: 0 -127
T1:T.B.A.
T2: 0 - 255
T3: 0 - 511
N.A. yes 0 -
32767
T6 Unsigned integer default
format
