Note:
The format for tag variables for the PLC-5 is:Xf:e.s/_d, where the _d is defined as the destination
address. However, the destination address is not supported in Full Duplex protocol. The destination
address is ignored because it's talking to the program port. Half Duplex does support the _d destination
address.
Just as a reminder, when working with Full Duplex, you have to set up the PLC Channel 0 to Point-to-
Point. For Half Duplex, Channel 0 must be set to System (Slave).
