Allen-Bradley SLC 500

QUICKDESIGNER Allen-Bradley •
••
• 49
T4:000.
or Tn:000.
4 999 0-999
(.ACC, .PRE, .EN, .TT,
.DN)
Y 0 to +32767
C5:000.
or Cn:000.
5 999 0-999
(.ACC, .PRE, .DN, .CU,
.CD, .OV, .UN, .UA)
Y -32768 to +32767
R6:000.
or Rn:000.
6 999 0-999
(.LEN, .POS, .DN, .EN,
.ER, .UL, .IN, .FD)
Y -32768 to +32767
N7:000
or Nn:000
7 999 0-999 /0 - /15 Y -32768 to +32767
ND
(Double)
7 999 0-999 Y -2147M to 4294M
NL (Long) 7 999 0-999 Y -2147M to 4294M
D8 or Dn: 8 999 0-999 Y 0 to 9999
F8 or Fn: 8 999 0-999 Y -2147M to 4294M
A8 or An: 8 999 0-999 Y Null - ASCII
ST 8 999 0-999 Y Null - ASCII
Note 1: File Type ranges other than the default value shown in 'File Type # Min' are 8-999.
Note 2: Address range for I & O are in rrg (rr=rack num., g=group num.) Address Max for S is dependent on the
PLC.
Note 3: Bits may wrap into other words. EX: B3:5/41 = B3:7/9 Bit format is Decimal.
Note 4: Integer types (range –32768 to 32767) may be configured as unsigned (range 0 – 65535). Data format is
16 bit Decimal.
Note 5: These are system variables. Use caution when writing to S variable types.
Note 6: O and I bits can use octal addressing by adding 'o' to the bit address. EX: I1:2/o17.
Note 7: Default format for I/O is Octal words and Decimal Bits
