ATEN KE6900T - KE6900; KE6940 Point-to-Point Installation 2 of 2

Chapter 2. Hardware Setup
87
Note: The diagram above shows KE6900T and KE6900R. The KE6940
installation is the same except that an additional DVI monitor can be
connected at each end for a dual-display setup.
KE6900 / KE6940 Point-to-Point Installation 2 of 2
Note: The serial port on the transmitter (shown above) connects to the
computer, while the serial port on the receiver (not shown) connects to
a serial device (optional).
2
USB KVM
cable
Local PC
3
4
KE6900T
