KVM over IP Matrix System User Manual
328
Control Panel Functions
The Control Panel functions are described in the table below.
Icon Function
This is a toggle. Click to ping the Control Panel to the window where
it is always displayed on top of other screen elements. Click again to
have it display normally.
Click to bring up the Video Options dialog box. (See Video Settings,
page 332, for details).
Toggles the display between Full Screen Mode and Windowed
Mode.
Click to take a snapshot (screen capture) of the remote display. To
configure the Snapshot parameters, refer to Snapshot on page 343.
Click to toggle the remote display between color and grayscale.
Click to zoom the remote display window.
Note: This feature is only available in windowed mode (Full Screen
Mode is off). See Zoom, page 338 for details.
Click to send a Ctrl+Alt+Del signal to the remote system.
Click to bring up the on-screen keyboard (see The On-Screen
Keyboard, page 339).
Click to select the mouse pointer type.
Note: This icon changes depending on which mouse pointer type is
selected (see Mouse Pointer Type, page 340).
Click to toggle Automatic or Manual mouse sync.
When the selection is Automatic, a green mark appears on the
icon.
When the selection is Manual, a red mark appears on the icon.
See Mouse DynaSync Mode, page 340 for a complete explanation
of this feature.
