KE8950 / KE8952 Network Installation Diagram 1 of 2
Note: Power adapters are not provided with KE8952 units. Please contact
your ATEN dealer to purchase additional power adapters, or use the
Power over Ethernet (PoE) feature to supply power to KE8952 units.
KE8950R (Rear)
6
KE8950T (Rear)
8
5
1
Cat 5e/6 Cable
7
Optical Fiber Cable
Cat 5e/6 Cable Optical Fiber Cable
9
DC 5V
DC 5V
TCP/IP
LAN
