Chapter 2. Hardware Setup
107
KE8950 / KE8952 Point-to-Point Installation 1 of 2
Note: Power adapters are not provided with the KE8952. Please contact your
ATEN dealer to purchase additional power adapters, or use the Power
over Ethernet (PoE) feature to supply power to the KE8952.
KE8950R (Rear)
6
KE8950T (Rear)
8
5
1
Cat 5e/6 Cable
7
Optical Fiber Cable
Cat 5e/6 Cable Optical Fiber Cable
9
DC 5V
DC 5V
