ATEN KE6900T - KE6940 AiT Point-to-Point Installation 2 of 2

Chapter 2. Hardware Setup
93
Note: The diagram above shows a KE6940AiT installation with KE6940AR.
The KE6900AiT installation is the same except with one less DVI
monitor.
KE6940AiT Point-to-Point Installation 2 of 2
Note: The serial port on the transmitter (shown above) connects to the
computer, while the serial port on the receiver (not shown) connects to
a serial device (optional).
KE6940AiT (Front)
5
3
4
USB DVI-D KVM
cable
